Xerox Phaser 6280 Service Manual

9-18 Phaser 6280 Color Laser Printer Service Manual
Parts List
41. -----
42. Shaft Feed
43. -----
44. Support Nudger Assy
45. Shaft Nudger
46. Gear Nudger A4
47. Gear Idler Nudger
48. Holder No Paper Left A4
49. Actuator No Paper A4
50. Holder No Paper Right A4
51. Clutch Oneway Nudger
52. Clutch Oneway Feed
53. Roll Assy Feed (Periodic Replacement Part - per 100K prints)
(consist of 3 pcs and tech sheet)
PL2.2.17
54. -----
55. Cover OHP Sensor
56. -----
57. -----
58. -----
59. Nudge Assy (with 44-50) 068K61240
60. -----
61. PWBA TEM Sensor
62. Harness Assy TEM Sensor (J301-J2411)
99. Kit Feeder Assy (with 3.2.1, 23, 24) 675K74270
Parts List 3.2 Paper Feeder (2 of 2) (continued)
ID No. Name/Description Part Number

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
