YASKAWA Sigma II Series User Manual

12.3 List of Parameters
12-35
12
Appendix
* Used only when the software version is 32 or later.
Parameter
No.
Name Setting Range Unit
Factory
Setting
Setting
Validation
Reference
Section
Pn40A
First Stage Notch Filter Q Value
*
50 to 400
(0.50 to 4.00)
×0.01 70
(0.70)
Immedi-
ately
10.3.4
Pn40B
Second Stage Notch Filter Frequency
*
50 to 2000 1 Hz 2000 Immedi-
ately
10.3.4
Pn40C
Second Stage Notch Filter Q Value
*
50 to 400
(0.50 to 4.00)
×0.01 70
(0.70)
Immedi-
ately
10.3.4
Pn500 Positioning Completed Width
0 to 250 1 reference
unit
7Immedi-
ately
8.6.5
Pn501 Zero Clamp Level
0 to 10000
1 min
-1
10 Immedi-
ately
8.5.6
Pn502 Rotation Detection Level
1 to 10000
1 min
-1
20 Immedi-
ately
8.11.3
Pn503 Speed Coincidence Signal Output Width
0 to 100
1 min
-1
10 Immedi-
ately
8.5.8
Pn504 NEAR Signal Width
1 to 250 1 reference
unit
7Immedi-
ately
8.6.6
Pn505 Overflow Level
1 to 32767 256 refer-
ence units
1024 Immedi-
ately
9.3.3
Pn506
Brake Reference
-
Servo OFF Delay Time
0 to 50 10 ms 0 Immedi-
ately
8.3.4
Pn507 Brake Reference Output Speed Level
0 to 10000
1 min
-1
100 Immedi-
ately
8.3.4
Pn508 Timing for Brake Reference Output during
Motor Operation
10 to 100 10 ms 50 Immedi-
ately
8.3.4
Pn509 Momentary Hold time
20 to 1000 1 ms 20 Immedi-
ately
8.3.6
