No. Name Description Range Default
F6-41 CompoNet Speed
0: 93.75 kbit/s
1: Reserved
2: 1.5 Mbit/s
3: 3 Mbit/s
4: 4 Mbit/s5-25
5: Reserved
0 to 255 0
n
F7-01 to F7-04: Ethernet IP Address 1 to 4
Parameter Overview
No. Name Description Range Default
F7-01 Ethernet IP Address 1
Combining these parameters like F7-01.F7-02.F7-03.F7-04 sets the Ethernet IP
address.
Example: (192.168.1.10)
0 to 255 0
F7-02 Ethernet IP Address 2 0 to 255 0
F7-03 Ethernet IP Address 3 0 to 255 0
F7-04 Ethernet IP Address 4 0 to 255 0
n
F7-05 to F7-08: Subnet Mask 1 to 4
Parameter Overview
No. Name Description Range Default
F7-05 Subnet Mask 1
Combining these parameters like F7-05.F7-06.F7-07.F7-08 sets the Ethernet
Subnet Mask.
Example: (255.255.255.0)
0 to 255 0
F7-06 Subnet Mask 2 0 to 255 0
F7-07 Subnet Mask 3 0 to 255 0
F7-08 Subnet Mask 4 0 to 255 0
n
F7-09 to F7-12: Gateway Address 1 to 4
Parameter Overview
No. Name Description Range Default
F7-09 Gateway Address 1
Combining these parameters like F7-09.F7-10.F7-11.F7-12 sets the Ethernet
Gateway Address.
Example: (192.168.1.1)
0 to 255 0
F7-10 Gateway Address 2 0 to 255 0
F7-11 Gateway Address 3 0 to 255 0
F7-12 Gateway Address 4 0 to 255 0
n
F7-13: Dress Mode at Startup
Parameter Overview
No. Name Description Range Default
F7-13 Dress Mode at Startup
Selects how the Ethernet IP address is set.
0:User defined
1:BOOTP
2:DHCP
0 to 2 0
n
F7-14: Security Password
Parameter Overview
No. Name Description Range Default
F7-14 Security Password
Sets the password required for setup changes via the network.
0: No password required
1 - 9999: 4 digit password
0 to 9999 0
n
F7-15: Duplex Mode Selection
Parameter Overview
No. Name Description Range Default
F7-15 Duplex Mode Selection
0:Auto Negotiate
1:Half Duplex forced
2:Full Duplex forced
0 to 2 0
n
F7-18: Communication Speed Selection
Parameter Overview
No. Name Description Range Default
F7-18 Communication Speed Selection
0:Auto Negotiate
10:10 Mbps speed setting
100:100Mbps Speed Setting
0, 10, 100 0
n
F7-19: Web Page Access
Parameter Overview
5.6 F: Option Settings
158
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
