YASKAWA V1000 Series

Par. Description Unit Default Settings
n8-49 Pull-in current % 0 0 0 0 0
Table B.9 3600 rpm Yaskawa Pico Motor Settings
Par. Description Unit Default Settings
E5-01
Motor Code − 0103 0105 0106 0108
Voltage class Rated power − 200 Vac 0.75 kW 200 Vac 1.5 kW 200 Vac 2.2 kW 200 Vac 3.7 kW
Rated speed min-1 3600 3600 3600 3600
E5-02 Motor rated power kW 0.75 1.5 2.2 3.7
E5-03 Motor rated current A 4.1 8.0 10.5 16.5
E5-04 Motor pole number – 8 8 8 8
E5-05 Motor winding resistance
Ω
0.538 0.20 0.15 0.097
E5-06 d-axis inductance mH 3.2 1.3 1.1 1.1
E5-07 q-axis inductance mH 3.2 1.3 1.1 1.1
E5-09 Induction voltage constant 1 mVsec/rad 0 0 0 0
E5-24 Induction voltage constant 2 mV/min-1 32.4 32.7 36.7 39.7
E1-04 Maximum output frequency Hz 240 240 240 240
E1-05 Maximum output voltage V 200.0 200.0 200.0 200.0
E1-06 Base voltage Hz 240 240 240 240
E1-09 Minimum output voltage Hz 12 12 12 12
L3-24 Motor acceleration time s 0.064 0.066 0.049 0.051
n8-49 Pull-in current % 0 0 0 0
n
SS5 Motor: Yaskawa SSR1 Series IPM Motor
Table B.10 200 V, 1750 rpm Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1202 1203 1205 1206 1208
Voltage class Rated power − 200 Vac 0.4 kW 200 Vac 0.75 kW 200 Vac 1.5 kW 200 Vac 2.2 kW 200 Vac 3.7 kW
Rated speed min-1 1750 1750 1750 1750 1750
E5-02 Motor rated power kW 0.4 0.75 1.5 2.2 3.7
E5-03 Motor rated current A 1.65 2.97 5.50 8.10 13.40
E5-04 Motor pole number – 6 6 6 6 6
E5-05 Motor winding resistance
Ω
8.233 2.284 1.501 0.827 0.455
E5-06 d-axis inductance mH 54.84 23.02 17.08 8.61 7.20
E5-07 q-axis inductance mH 64.10 29.89 21.39 13.50 10.02
E5-09 Induction voltage constant 1 mVsec/rad 233.0 229.5 250.9 247.9 248.6
E5-24 Induction voltage constant 2 mV/min-1 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum output frequency Hz 87.5 87.5 87.5 87.5 87.5
E1-05 Maximum output voltage V 190.0 190.0 190.0 190.0 190.0
E1-06 Base voltage Hz 87.5 87.5 87.5 87.5 87.5
E1-09 Minimum output voltage Hz 4.4 4.4 4.4 4.4 4.4
L3-24 Motor acceleration time s 0.092 0.076 0.051 0.066 0.075
n8-49 Pull-in current % –7.2 –10.8 –11.1 –17.8 –17.5
Par. Description Unit Default Settings
E5-01
Motor Code − 120A 120B 120D 120E
Voltage class Rated power − 200 Vac 5.5 kW 200 Vac 7.5 kW 200 Vac 11 kW 200 Vac 15 kW
Rated speed min-1 1750 1750 1750 1750
E5-02 Motor rated power kW 5.5 7.5 11.0 15
E5-03 Motor rated current A 19.80 27.00 39.7 53.2
E5-04 Motor pole number – 6 6 6 6
E5-05 Motor winding resistance
Ω
0.246 0.198 0.094 0.066
E5-06 d-axis inductance mH 4.86 4.15 3.40 2.65
E5-07 q-axis inductance mH 7.43 5.91 3.91 3.11
E5-09 Induction voltage constant 1 mVsec/rad 249.6 269.0 249.3 266.6
E5-24 Induction voltage constant 2 mV/min-1 0.0 0.0 0.0 0.0
E1-04 Maximum output frequency Hz 87.5 87.5 87.5 87.5
E1-05 Maximum output voltage V 190.0 190.0 190.0 190.0
E1-06 Base voltage Hz 87.5 87.5 87.5 87.5
E1-09 Minimum output voltage Hz 4.4 4.4 4.4 4.4
L3-24 Motor acceleration time s 0.083 0.077 0.084 0.102
n8-49 Pull-in current % –22.0 –17.3 –10.1 –10.3
Table B.11 400 V, 1750 rpm Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1232 1233 1235 1236 1238
Voltage class Rated power − 400 Vac 0.4 kW 400 Vac 0.75 kW 400 Vac 1.5 kW 400 Vac 2.2 kW 400 Vac 3.7 kW
Rated speed min-1 1750 1750 1750 1750 1750
E5-02 Motor rated power kW 0.4 0.75 1.5 2.2 3.7
E5-03 Motor rated current A 0.83 1.49 2.75 4.05 6.80
E5-04 Motor pole number – 6 6 6 6 6
E5-05 Motor winding resistance
Ω
32.932 9.136 6.004 3.297 1.798
E5-06 d-axis inductance mH 219.36 92.08 68.32 40.39 32.93
B.2 Parameter Table
326
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
