YASKAWA V1000 Series

Par. Description Unit Default Settings
E5-07 q-axis inductance mH 256.40 119.56 85.56 48.82 37.70
E5-09 Induction voltage constant 1 mVsec/rad 466.0 459.0 501.8 485.7 498.7
E5-24 Induction voltage constant 2 mV/min-1 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum output frequency Hz 87.5 87.5 87.5 87.5 87.5
E1-05 Maximum output voltage V 380.0 380.0 380.0 380.0 380.0
E1-06 Base voltage Hz 87.5 87.5 87.5 87.5 87.5
E1-09 Minimum output voltage Hz 4.4 4.4 4.4 4.4 4.4
L3-24 Motor acceleration time s 0.092 0.076 0.051 0.066 0.075
n8-49 Pull-in current % –7.2 –10.7 –11.1 –8.9 –7.9
Par. Description Unit Default Settings
E5-01
Motor Code − 123A 123B 123D 123E
Voltage class Rated power − 400 Vac 5.5 kW 400 Vac 7.5 kW 400 Vac 11 kW 400 Vac 15 kW
Rated speed min-1 1750 1750 1750 1750
E5-02 Motor rated power kW 5.5 7.5 11.0 15
E5-03 Motor rated current A 9.90 13.10 19.9 26.4
E5-04 Motor pole number – 6 6 6 6
E5-05 Motor winding resistance
Ω
0.982 0.786 0.368 0.263
E5-06 d-axis inductance mH 22.7 16.49 13.38 10.51
E5-07 q-axis inductance mH 26.80 23.46 16.99 12.77
E5-09 Induction voltage constant 1 mVsec/rad 498.0 541.7 508.7 531.9
E5-24 Induction voltage constant 2 mV/min-1 0.0 0.0 0.0 0.0
E1-04 Maximum output frequency Hz 87.5 87.5 87.5 87.5
E1-05 Maximum output voltage V 380.0 380.0 380.0 380.0
E1-06 Base voltage Hz 87.5 87.5 87.5 87.5
E1-09 Minimum output voltage Hz 4.4 4.4 4.4 4.4
L3-24 Motor acceleration time s 0.083 0.077 0.084 0.102
n8-49 Pull-in current % –10.2 –17.4 –15.8 –12.6
B.2 Parameter Table
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
327
B
Parameter List
