465
Trans/Dist
Use this tab to adjust the settings for the Transient and Distortion effects.
Parameter Description Value Range
Transient Attack Decreases or increases the amount of
transient attack applied to the signal.
-100 – 0 – +100%
Shape Adjusts the shape of the processed transient. 0–100%
Sustain Percentage of sustain envelope subtracted
from or added to the transient effect.
-100 – 0 – +100%
Distortion Pre-Shape Increases or decreases the high-end tone of
the incoming audio signal pre-distortion.
-100 – 0 – +100%
Drive Amount of drive applied. 0–60 dB
Threshold Signal level after which the distortion will be
applied.
-20.0–0.0 dB FS
High Cut Center frequency of the distortion signal high-
cut filter.
1.00–20.0 kHz
Mix Wet/dry amount of the distortion effect. 0–100%
EQ/Comp
Use this tab to adjust the settings for the EQ and Compressor effects.
Parameter Description Value Range
EQ High Freq Center frequency for the High EQ band. 1.20 – 20.0 kHz
High Gain Amount of gain applied to the High EQ band. Cut, -12.0 – 0 – +12.0 dB
High Mid Freq Center frequency for the High Mid EQ band. 120 Hz – 16.0 kHz
High Mid Q Width of the High Mid EQ band. 0.40–10.00
High Mid Gain Amount of gain applied to the High Mid EQ
band.
-18.0 – 0 – +18.0 dB
Low Mid Freq Center frequency for the Low Mid EQ band. 40.0 Hz – 8.00 kHz
Low Mid Q Width of the Low Mid EQ band. 0.40–10.00
Low Mid Gain Amount of gain applied to the Low Mid EQ
band.
-18.0 – 0 – +18.0 dB
Low Freq Center frequency for the Low EQ band. 20.0 Hz – 1.00 kHz
Low Gain Amount of gain applied to the Low EQ band. Cut, -12.0 – 0 – +12.0 dB
Compressor Ratio Amount of compression applied. 1.0:1 – 100.0:1
Attack Length of time to apply the compression. 100 us – 300 ms
Threshold Signal level after which the compressor will
be applied.
-60.0–0.0 dB
Output Amount of additional output gain for the
compressed signal.
0.0–30.0 dB
