Introduction Configuring LAG
Software Reference for SwitchBlade x3100 Series Switches (Layer Two Switching)
4-32
enabled for both the system and related ports, or have ensured that all interfaces except the ones
that were in the LAG group have been disabled or disconnected.
The following procedure shows the commands used to destroy the LAG created in the procedure shown in
Figure 4-2.
TABLE 4-4 Configuration Procedure for Destroying a LAG
Step Command Description/Notes
Tu r n o f f L AG m o d e
1
set lag sfp mode off Sets the mode for LAG “sfp” to OFF.
Verify that LAG mode is off
2
show lag
--- LAG Info Data -------------------------------------------------------
LAG Name Provisioned Ports Mode Select Criteria Admin Key Index
------------------------------- ----------------------------------------------------------
sfp 0.8-0.9, 3.0 off portboth & ipboth 1 0
& macboth
LAG Name Enabled Ports Speed Oper State Dir Interface ID
------------------------------- ----------------------------------------------------------
sfp None 0 Gbps Down Ntwk LAG:0
Delete all of LAG’s member interfaces
3
delete lag sfp interface 0.8,0.9,3.0 Deletes interfaces 0.8, 0.9 and 3.0 from the
LAG.
Destroy the LAG
4
destroy lag sfp Destroys the LAG.
Verify that LAG has been destroyed
5
show lag
--- LAG Info Data -----------------------------------------------------------------------
LAG Name Provisioned Ports Mode Select Criteria Admin Key Index
------------------------------- ---------------------------------------------------------
LAG Name Enabled Ports Speed Oper State Dir Interface ID
------------------------------- ----------------------------------------------------------
