Configuring Standard VLANs Introduction
4-49
Software Reference for SwitchBlade x3100 Series Switches (Layer Two Switching)
The following procedure shows how to create several standard VLANs using a single command.
6
show vlan videoHD full
--- VLAN Information ----------------------------------------------------------
Type.................................. VLAN
Name.................................. videoHD
Identifier............................ 4004
Status................................ Static
Forwarding Mode....................... Standard
IP module attached.................... <none>
Untagged Interfaces
Downstream.......................... <none>
Downstream (restricted)............. <none>
Tagged Interfaces
Downstream.......................... ETH:[0.23]
Downstream (restricted)............. <none>
VLAN Translation interfaces........... <none>
Destroy the VLAN. (Before a VLAN can be destroyed, all its associated interfaces must be deleted.)
7
delete vlan 4004 interface 0.23
DESTROY VLAN=4004
Deletes interface 0.23 from VLAN 4004.
Destroys VLAN 4004.
Verify that VLAN has been destroyed
8
SHOW VLAN=4004
--- VLAN Information ----------------------------------------------------------
No information to display
TABLE 4-9 Configuration Procedure - Creating Multiple VLANs at Once
Step Command Description/Notes
Create a series of VLANs. Rather than specifying the VLAN names. Specify a range of desired VIDs.
1
CREATE VLAN VID=3201-3210 Creates a series of 10 VLAN with VIDs that
range from 3201 to 3210. The system sequen-
tially assign names to the VLANs -- based on
the range of VIDs.
TABLE 4-8 Configuration Procedure for Creating a Standard VLAN
Step Command Description/Notes
