Introduction Configuring Standard VLANs
Software Reference for SwitchBlade x3100 Series Switches (Layer Two Switching)
4-58
SET VLAN INTERFACE
Description The SET VLAN INTERFACE command specifies:
- the framing type (tagged or untagged) on the interfaces in a Virtual LAN (VLAN)
- an interface's forwarding role for VLANs that are in UPSTREAMONLY forwarding
mode
- the VLAN identifier from which the VLAN is to be translated
Syntax
SET VLAN={ vlanname-list | vid-range } INTERFACE={ type:id-range |
id-range | ifname-list | ALL } [ FRAME={ UNTAGGED | TAGGED } ] [
TRANSLATE={ 1..4094 | NONE } ] [ FORWARDING={ PRIMARYUPSTREAM |
SECONDARYUPSTREAM | DOWNSTREAM | RESTRICTED | STP | UCP | EPSR } ]
Options The following table gives the range of values for each option that can be specified with
this command and a Default Value (if applicable).
Option Description Default Value
INTERFACE Specifies the type of physical port. For a VLAN,
interfaces can have a type of ETH or LAG. The
LAG interface type can have more than one physi-
cal ports associated with it.
Interfaces can be queried by using 'type:id-range',
'name-list' or 'ALL' options. For example, 'ETH:2.0',
'ETH:2.1-2.4', where 2.0,2.1 etc. are the actual
physical ports and are used as the interface Id's in
this representation.
N/A
FRAME Specifies whether a VLAN tag header is included in
each frame transmitted on the specified interfaces.
TAGGED - a VLAN tag is added to frames prior to
transmission. The interface is then called a tagged
interface for this VLAN.
UNTAGGED - the frame is transmitted without a
VLAN tag. The interface is then called an untagged
interface for this VLAN.
N/A
TRANSLATE Specifies the VLAN identifier from which the
VLAN is translated.
N/A
