Software Reference for SwitchBlade x3100 Series Switches (Layer Two Switching)
4-94
4
SHOW STP
--- STP Information ------------------------------------------------------
Spanning Tree Type...................... RSTP
Instance Name......................... MAIN (0)
Instance State........................ ENABLED
Root Bridge ID Priority................. 32768
(output omitted)
Int Role State Cost Prio.Number Type
----- ---------- ---------- ---------- ----------- ---------------------
0.0 ROOT FORWARDING 20000 128.321 RSTP
0.22 ALTERNATE DISCARDING 20000 128.343 RSTP
0.23 DESIGNATED FORWARDING 200000 128.344 RSTP
1.2 DESIGNATED FORWARDING 2000 128.387 RSTP
1.3 DESIGNATED FORWARDING 2000 128.388 RSTP
SHOW STP INTERFACE=0.23 FULL
------------- STP Information for Port 0.23 -----------------------------
Spanning Tree Instance Name........... MAIN (0)
Port ID............................... 33112
Role................................ DESIGNATED
State............................... FORWARDING
Priority............................ 128
Pathcost............................ 200000
(output omitted)
BPDU Cop.............................. ON
timeout............................. 10
If a loop occurs, BPDU Cop disables the interface, sends a SYSLOG, and raises an alarm.
5
SHOW INTERFACE=0.23
--- GE Interfaces ---
Interface.......................... 0.23
Type............................... GE
State.............................. UP-DN-AutoDisabled
Description........................ <none>
Remote ID.......................... <none>
External Profile................... <none>
Card Type.......................... GE24SFP
Interface Faults
Unexpected BPDU Received........ Major
(output omitted)
TABLE 4-15 Configuration Procedure for BPDU Cop
Step Command Description (Optional)
