Masimo Patient Cables and Sensors
When selecting a sensor, consider the patient’s weight, the adequacy of perfusion, the available sensor
sites, and the duration of monitoring. Use only Masimo
SET sensors. Select an appropriate sensor, apply it
as directed, and observe all warnings and cautions presented in the user manual accompanying the sensor.
For a list of compatible sensors and cables, refer to the Masimo Monitor Sensor Compatibility Card,
Alaris
TM
SpO
2
Module 8220 Series.
Features and Displays
Features and Definitions
See Features and Displays on page 52 for system features and definitions.
Models 8210 and 8220
Feature Definition
% SpO
2
Alarm Limits Upper and lower saturation limits for %SpO
2
alarm can be adjusted by clinician.
% SpO
2
Display Functional arterial hemoglobin oxygen saturation is displayed in units of percentage
SpO
2
.
Limit Mode Configurable mode that can be set to display either adult or neon
atal monitoring
mode. (See
Configurable Settings on page 277 for additional configurable features.)
Pleth Waveform Plethysmographic (pleth) waveform is a graphic representation of changes in
extremity blood volume during cardiac cycle events. Displayed waveform is a
simulated signal (non-normalized).
Pulse Beat Volume Sound of each pulse beep can be configured to be off or to a volum
e level of 1, 2, or 3.
Pulse Rate Displayed in beats per minute (bpm).
Pulse Rate Alarm Limits Upper and lower pulse rate alarm limits can be adjusted by clinician.
Trend Data Tabular display of %SpO
2
and pulse rate. Display shows average high and low values,
and alarm conditions for time period displayed. Up to 24 hours of data is stored.
(8220)
