BD Alaris - Displays; Configurable Settings

General Information
BD Alaris
TM
System with Guardrails
TM
Suite MX User Manual 249
Displays
The displays illustrated throughout this document are for illustration purposes only. The display content
varies, depending on configuration settings, type of administration set in use, hospital-defined da
ta set
uploaded using the Guardrails suite MX, programmed drug calculation parameters, and many other
variables. Refer to specific drug product labeling for information concerning appropriate administration
techniques and dosages.
Configurable Settings
See the This chapter contains the following topics: on page 15 for system configurable settings.
The configuration settings are selected during d
ata set development and then uploaded to the system as part
of the data.
With the profiles feature enabled, the settings are configured independently for each profile. A
hospital-defined, best practice data set must be uploaded to enable the profiles feature. Date and time is a
system setting and is the same in all profiles.
Feature Default Setting Options
Authorization Code None 4 digits (0 - 9)
One code applies to all profiles
Bolus Delivery Rate 150 mL/h 75 - 500 mL/h (limited by syringe size)
Bolus Dose Disabled Enabled - Disabled
Bolus Dose include in Max. Limit Disabled Enabled - Disabled
Dose Request Cord Configuration Profile 2 Profile 1, 2, 3
Forced Module Location Enabled Enabled - Disabled
Loading Dose Disabled Enabled- Disabled
Lockout Interval 1 - 99 minutes in 1-minute
increments
Min/Max 1 - 99 minutes
Max Accumulated Dose Range 4-hour limit Disabled; 1, 2, or 4-hour limit
Max Rate (for Continuous Dose)

999 mL/h 0.1 - 99.9 mL/h in 0.1 mL/h increments;
100 - 999 mL/h in 1 mL/h increments
NEOI
• Alert Time
Disabled Enabled - Disabled
5 - 25% of syringe size
NEOI Snooze

Disabled 5, 10 or 15 minutes
Occlusion Pressure Set Point High (800 mmHg) Low (200 mmHg)
Medium (500 mmHg)
High (800 mmHg)
