Chapter 3—BD Alaris™ Pump Module Model 8100, Alaris™ Pump Module Model 8100, and Alaris™
Syringe Module Model 8110
114 BD Alaris
TM
System with Guardrails
TM
Suite MX User Manual
Manual Programming — Secondary Infusion (Pump Module)
This mode is designed to support the delivery of secondary infusions (“piggybacking”) in the same
module. A secondary infusion can be programmed as a No Guardrails - Basic Infusion or Drug Library
Infusion. When the secondary
VTBI reaches zero, an audio tone sounds (if enabled) indicating completion
of the secondary infusion. The primary infusion resumes automatically.
When the instrument is programmed and delivering in the secondary mod
e, the primary infusion is
temporarily stopped and fluid is drawn from the secondary container. Delivery from the primary container
resumes when
the fluid level in the secondary line is level with the fluid in the primary container.
NOTE:
When primary sets without a check valve are used, the clinician must manually clamp of
f the primary line
during the secondary infusion and then manually unclamp the line once the secondary VTBI reaches zero.
Setup
1. Open secondary administration set package, remove set and close clamp.
2. Insert administration set spike into prepared
fluid container and hang secondary container, following
accepted hospital/facility procedure.
3. Fill drip chamber to
⅔ full.
4. Open secondary administration set cl
amp and prime set. Close clamp.
5. Attach secondary administration set to upper injection site on prima
ry set.
6. Using the hanger provided with secondary administration set,
lower the primary fluid container to
height indicated in following illustrations.
Secondary applications require the use of a check valve or clamp on the primary IV
line in order to prevent backflow of secondary medication into the primary line.
The secondary administration set must be primed prior to beginning the secondary infusion.
The secondary solution container must be higher than the primary solution container.
