General Information
BD Alaris
TM
System with Guardrails
TM
Suite MX User Manual 191
Syringe Module
Bolus Volume,
Maximum after
Occlusion:
Bolus Volume, Maximum after Occlusion is measured using two different setups.
The first setup simulates an actual clinical setup and includes a device at heart height, a full
length administration set, and an 18 gauge needle at the end of the administration set. Test setup
uses a BD 50/60 mL syringe at 5 mL/h.
Use the smallest compatible syringe size necessary to deliver the fluid or
medication; this is especially important when infusing high risk or
life-sustaining medications at low infusion rates.
The second setup is a laboratory test setup that includes a 1 meter administration set, a device
above the height of the collection container, rigid tubing connecting the administration set to a
pressure transducer, and no needle at the end of the administration set.
Clinical Simulation Test Setup
Without Pressure Sensing Disc:
With Pressure Sensing Disc:
Pressure Setting Bolus Volume (mL)
Low 0.512
Medium 0.776
High 1.103
Pressure Setting
Bolus Volume (mL)
Back Off Disabled Back Off Enabled
300 mmHg 0.462 0.126
500 mmHg 0.575 0.331
1000 mmHg 0.839 0.323
