Chapter 3—BD Alaris™ Pump Module Model 8100, Alaris™ Pump Module Model 8100, and Alaris™
Syringe Module Model 8110
192 BD Alaris
TM
System with Guardrails
TM
Suite MX User Manual
Laboratory Test Setup
Without Pressure Sensing Disc:
With Pressure Sensing Disc:
The system has a back-off safety feature that, when enabled and a pressure sensing disc is in
use, is designed to reduce bolus volume on occlusion release.
Installing a pressure sensing disc after an infusion has started can
result in a bolus to the patient.
Maximum Bolus Volume specifications are based on following standard operating conditions:
Atmospheric Pressure: 645 - 795 mmHg
Disposable Type:
No Pressure Disc: #30914
With Pressure Disc: #10014917
Humidity: 20 - 90%
Rate: 5 mL/h
Syringe Type: BD 50/60 mL (Clinical),
BD
20 mL (Laboratory)
Temperature: 68 ±4°F
Volume Collection Time: approximately 2 minutes
Critical
Volume:
Maximum over-infusion which can occur in the event of a single-fault condition will not exceed
2% of nominal syringe fill volume during loading and 1% of maximum syringe travel after
syringe loading.
Dimensions:
4.75" W x 15.0" H x 7.5" D
Pressure Setting Bolus Volume (mL)
Low 0.350
High 0.560
Pressure Setting
Bolus Volume (mL)
Back Off Disabled Back Off Enabled
25 mmHg 0.170 0.160
1000 mmHg 0.610 0.450
