Chapter 6—Alaris™ EtCO
2
Module Model 8300
300 BD Alaris
TM
System with Guardrails
TM
Suite MX User Manual
Specifications and Symbols
Specifications
Accuracy:
EtCO
2
readings
NOTE:
Accuracy applies for breath rates of up to 80 bpm. For breath rates above
80 bpm, accuracy is 4 mmHg or ±12% of reading whichever is greater, for
EtCO
2
values exceeding 18 mmHg. This is tested by Medtronic according
to and is compliant with ISO 80601-2-55. To achieve the specified
accuracies for breath rates above 60 breaths/minute, the Microstream
FilterLine H Set for Infant/Neonatal must be used. Above 55ºC module
temperature, ± 1mmHg or ± 2.5%, whichever is greater, has to be added to
t
he
tolerance of the accuracy specifications.
The accuracy specification is maintained to within 4% of the values in the presence of
interfering gases.
Above 55°C module temperature, ±1 mmHg or 2.5% (whichever
is greater), has to be
added to tolerance of accuracy specifications.
Respiration rate, measured in range of 0 - 150 bpm with following accura
cy:
0 - 70 bpm: ±1 bpm
71 - 120 bpm: ±2 bpm
121 - 150 bpm: ±3 bpm
Alarm Limits:
Alarms:
Audible and visual alarms for high and low EtCO
2
and respiratory rate, high
FiCO
2
, Microstream Disposable condition, system failure, no breath, and low
battery conditions.
Barometric Pressure:
EtCO
2
module
is equipped with automatic barometric pressure compensation.
There are no quantitative effects of barometric pressure for this device.
CO
2
Range:
Measures and reports partial pressures of CO2 in the range of 0 - 99 mmHg at
sea level. EtCO
2
and FiCO
2
values are calculated for all valid breaths.
Dimensions:
3.3" W x 8.9" H x 5.5" D
(8.4 cm W x 22.6 cm H x 14 cm D)
CO
2
Partial Pressure
(at sea level)
Accuracy
0 - 38 mmHg ±2 mmHg
39 - 99 mmHg ± (5% of reading + 0.08% for every
1 mmHg above 38 mmHg)
Low High
EtCO
2
0 - 98 mmHg 5 - 99 mmHg
FiCO
2
Not Applicable 2 - 99 mmHg
No Breath 10 - 60 sec Not Applicable
Respiration Rate 0 - 149 breaths/min 1 - 150 breaths/min
