NOTE:
The periodic auto zero function compensates
for drifts between components, changes in ambient
temperature and barometric conditions. This automatic process eliminates variances that might otherwise
cause measurement drift. Therefore the module does not exhibit drift.
Environmental Conditions:
Fluid Ingress Protection:
IPX2, Drip Proof
Frequency Response:
EtCO
2
accuracy applies for breath rates of up to 80 bpm. For maintaining
accuracy for respiration rates above 80 bpm, accuracy is 4 mmHg or ±12% of
reading, whichever is greater
, for EtCO
2
values exceeding 18 mmHg. To
achieve specified accuracies for breath rates above 60 bpm, Microstream
neonat
al airway adapter M1996A must be used.
Gas Interference:
The following liquid anesthetics have been tested and were found to have no effect:
• Desflurane
• Enflurane
• Halothane
• Isoflurane
• Sevoflurane
Internal Power Source:
Operating time (fully charged): 5.5 hours
Measurement Range:
Mode of Operation
Continuous
Sampling Gas Flowrate:
Nominally 50 mL/min -7.5 +15 mL/min
Shock Protection:
Type BF, defibrillation-proof patient applied part.
Total System Response
Time:
EtCO
2
module response: 4.9 seconds typical (includes rise time of 260 msec maximum).
Warm-Up Time:
30 seconds typical
Waveform Sampling:
20 samples/s
Weight:
2.5 lbs (1.13 kg)
Symbol Meaning Operating
Storage/
Transport
Atmospheric Pressure 525 - 795 mmHg
(70 - 106 kPa)
375 - 760 mmHg
(50 - 101 kPa)
Relative Humidity
(Avoid prolonged exposure to
relative humidity >90%)
20 - 90%
Noncondensing
5 - 90%
Noncondensing
Temperature Range 41 - 104°F
(5 - 40°C)
-4 - 140°F
(-20 - 60°C)
EtCO
2
: 0 - 99 mmHg
FiCO
2
: 0 - 99 mmHg
Respiratory Rate: 0 - 150 bpm
