BONFIGLIOLI Vectron Active Cube

start motion block
(control bit 9)
PLC
“ ” motion block sequence
sequence mode (control bit 4) = 1
sequence = motion block 4, 5, 6
Drive
target reached
(status bit 10)
motion block
in progress
(status bit 8)
position
active
motion block
0
4
5
6
0
