A
Value of a parameter is set via KP500 or VPlus. No “save” command.
1)
Setting of Maximum Frequency 419 = 48 Hz at KP500 or in VPlus.
2)
Power OFF and ON.
3)
The value of KP500/VPlus is active (48 Hz).
B
No “save” command. The value of the CANopen
®
object is overwritten.
1)
Setting of Maximum Frequency 419 = 48 Hz at KP500 or in VPlus.
2)
Setting of CANopen
®
object 0x6046 = 1140 rpm* (equivalent to 38 Hz).
3)
Power OFF and ON.
4)
Parameter value of KP500/VPlus overwrites the value of the CANopen
®
object. The value of KP500/VPlus is active (48 Hz).
C
“Save” command. The value of the CANopen
®
object is stored.
1)
Setting of Maximum Frequency 419 = 48 Hz at KP500 or in VPlus.
2)
Setting of CANopen
®
object 0x6046 = 1140 rpm* (equivalent to 38 Hz).
3)
“Save” command via CANopen
®
object 0x1010.
4)
Power OFF and ON.
5)
The value of CANopen
®
object 0x6046 is active (38 Hz).
D
“Save” command. The value of the CANopen
®
object is stored – even if the
corresponding parameter value has been changed after the “save” command.
1)
Setting of Maximum Frequency 419 = 48 Hz at KP500 or in VPlus.
2)
Setting of CANopen
®
object 0x6046 = 1140 rpm* (equivalent to 38 Hz).
3)
“Save” command via CANopen
®
object 0x1010.
4)
Setting of Maximum Frequency 419 = 48 Hz at KP500 or in VPlus.
5)
Power OFF and ON.
6)
Value of CANopen
®
object 0x6046 overwrites the parameter value. The
value of CANopen
®
object 0x6046 is active (38 Hz).
*
Internal conversion to a frequency value taking into account the No. of Pole Pairs 373.
In this example the number of pole pairs is two (four-pole machine).
NOTE
There are inverter parameters calculated from CANopen
®
objects which require the
no. of pole pairs for calculating the corresponding value for inverter parameters (e.
g. deceleration or acceleration parameters). These calculations always use the no.
of pole pairs from data set 1. If the no. of pole pairs is different in the data sets, the
result of this operation will not be clear for the user. To avoid confusion it is recom-
mended to write the inverter parameters via the SDO channel using the
0x2nnn
(manufacturer) objects and not to use the CANopen
®
objects. This way, inconsist-
encies are avoided.
All CANopen
®
DS402 objects with corresponding inverter parameters are pointed out
in this manual.
54 CM-CAN ACU 04/13
