Live View
36 ClareVision Plus Network Video Recorder User Manual
• Aux monitor: The NVR checks the connection of the output interfaces. The
priority level for the main and aux output is HDMI > VGA > CVBS. This means
if the HDMI is used, it is the main output. If HDMI is not used, the VGA output
is set as the main output. See Table 13.
Table 13: Priorities of interfaces
No.
HDMI
VGA
CVBS
Main output
Auxiliary output
1
√
√
√
HDMI
VGA
2
√
×
√
HDMI
CVBS
3
×
√
√
VGA
CVBS
4
×
×
√
CVBS
n/a
√ - the interface is in use.
× - the interface is not in use, or the connection is invalid.
HDMI, VGA and CVBS is used at the same time.
When the Aux output is enabled, the main output cannot operate. Some basic
operations are performed in the Live View mode for the Aux output.
Front panel operation in Live View
Table 14: Front panel operation in Live View mode
Functions
Front Panel Operation
Common menu
Provides quick access to the sub-menus most often visited. Up to 5
sub-menu options are supported.
Menu
When right-clicking the mouse, the menu displays.
Show multi-screen
Press the PREV/FOCUS.
Manually switch screens
Next screen: right/down direction button.
Previous screen: left/up direction button.
Auto-switch
Press Enter.
Playback
Press Play.
Switch between main
and aux output
Press Main/Aux.
