CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix K MN/CDM570L.IOM
K–7
(ODU: Enable) 1:1 Æ Red-Box
Redundancy Box: Online
Mode Switches Voltages
Use the
arrow keys to select Online, Mode, Switches, or Voltages, and then press
ENTER.
(ODU: Enable) 1:1 Æ Redundancy Box Æ Online
Online Unit:
CSAT#1 CSAT#2 ( ,ENT)
This display indicates the ODU currently online. The cursor will be flashing under
CSAT#1 or CSAT#2. If the need arises to change the Online unit, use the
arrow
keys to move the cursor position to the desired unit, and then press ENTER.
If the ODU Redundancy system is in AUTO mode, a ‘forced switch-over’
can only occurs if the currently Offline unit is fault-free.
(ODU: Enable) 1:1 Æ Redundancy Box Æ Mode
Operating Mode:
Manual Auto ( ,ENT)
This display indicates the current operating mode of the 1:1 ODU system. The cursor
will be flashing under Manual or Auto. If the need arises to change the operating mode of
the 1:1 system, use the
arrow keys to move the cursor position to the desired
operating mode, and then press ENTER.
(ODU: Enable) 1:1 Æ Redundancy Box Æ Switches
Waveguide Switch Status:
Tx=OK Rx=OK (ENT or CLR)
This read-only screen shows status for both the Tx and Rx Waveguide Transfer Switches.
If either Switch reports an ambiguity from the commanded position, “OK” will change to
FT” to indicate a switch fault.
(ODU: Enable) 1:1 Æ Redundancy Box Æ Voltages
Redundancy Box Voltages:
5V= 5.0 12V=12.0 (ENT)
Provided to assist in troubleshooting system problems, this read-only display monitors
the voltages inside the Redundancy Controller Box.
