CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix K MN/CDM570L.IOM
K–8
K.3.3.1.1.1.1 COMMON ‘ODU SELECT’ SUBMENU
(ODU: Enable) Standalone Æ
(ODU: Enable) 1:1 Æ CSAT#1 Æ
(ODU: Enable) 1:1 Æ CSAT#2 Æ
ODU SELECT: Config Info
Monitor Alarms (◄ ►,ENT)
Use the
◄ ► arrow keys to select Config, Info, Monitor, or Alarms, and then press ENTER.
K.3.3.1.1.1.1.1 ODU SELECT: Config
ODU CONFIG: Transmitter
Receiver Misc (◄ ►,ENT)
Use the
◄ ► arrow keys to select Transmitter, Receiver, or Misc,and then press ENTER.
(ODU SELECT) ODU CONFIG: Transmitter
ODU TX: Frequency Atten
Amplifier Mute Slope ◄ ►
Use the
◄ ► arrow keys to select Frequency, Atten, Amplifier, Mute, or Slope, and then
press ENTER.
(ODU SELECT) ODU CONFIG: ODU TX Æ Frequency
ODU Tx Frequency:
5912.5 MHz (◄ ►,▲ ▼,ENT)
To edit the transmit frequency: First, use the
◄ ► arrow keys to select a digit to edit, and
then use the
▲ ▼ arrow keys to change the value of that digit. Press ENTER when done.
(ODU SELECT) ODU CONFIG: ODU TX Æ Atten (Attenuation)
ODU Tx Attenuation:
15.00 dB (◄ ►,▲ ▼,ENT)
To edit the transmit attenuation: First, use the
◄ ► arrow keys to select a digit to edit, and
then use the
▲ ▼ arrow keys to change the value of that digit. Press ENTER when done.
(ODU SELECT) ODU CONFIG: ODU TX Æ Amplifier
ODU Tx Amp State:
On Off (◄ ►,ENT)
Use the
◄ ► arrow keys to select On or Off, and then press ENTER.
