CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix K MN/CDM570L.IOM
K–9
(ODU SELECT) ODU CONFIG: ODU TX ÆMute
ODU Tx Mute State:
Muted Unmuted (◄ ►,ENT)
Use the
◄ ► arrow keys to select Muted or Unmuted, and then press ENTER.
(ODU SELECT) ODU CONFIG: ODU TX ÆSlope
ODU Tx Slope Mode:
Manual Calibrated (◄ ►)
Use the ◄ ► the arrow keys to select Manual or Calibrated, and then press ENTER.
(ODU SELECT) ODU CONFIG: ODU TX ÆSlope Æ Manual
ODU Tx Slope:
0.0 (▲ ▼,ENT)
Use the
▲ ▼ arrow keys to edit the transmit slope setting, and then press ENTER.
(ODU SELECT) ODU CONFIG: Receiver
ODU RX: Frequency Atten
Mute Slope (◄ ►,ENT)
Use the ◄ ► the arrow keys to select Frequency, Atten, Mute, or Slope, and then press
ENTER.
(ODU SELECT) ODU CONFIG: ODU RX Æ Frequency
ODU Rx Frequency:
5912.5 MHz (◄ ►,▲ ▼,ENT)
To edit the receiver frequency: First, use the ◄ ► arrow keys to select a digit to edit, and
then use the
▲ ▼ arrow keys to change the value of that digit. Press ENTER when done.
(ODU SELECT) ODU CONFIG: ODU RX Æ Atten (Attenuation)
ODU Rx Attenuation:
15.00 dB (◄ ►,▲ ▼,ENT)
To edit the receiver attenuation: First, use the
◄ ► arrow keys to select a digit to edit, and
then use the
▲ ▼ arrow keys to change the value of that digit. Press ENTER when done.
(ODU SELECT) ODU CONFIG: ODU RX Æ Mute
ODU Rx Mute State:
Muted Unmuted (◄ ►,ENT)
Use the
◄ ► arrow keys to select Muted or Unmuted, and then press ENTER.
