CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix K MN/CDM570L.IOM
K–16
(ODU: Enable) KST CONFIG: Transmitter
KST TX: Frequency Atten
Output HPA (◄ ►,ENT)
Use the ◄ ► arrow keys to select Frequency, Atten, Output, or HPA, and then press
ENTER.
(ODU: Enable) KST CONFIG: KST TX Æ Frequency
ODU Tx Frequency:
14500.0 MHz (◄ ►,▲ ▼,ENT)
To edit the transmit frequency: First, use the
◄ ► arrow keys to select a digit to edit, and
then use the
▲ ▼ arrow keys to change the value of that digit. The frequency limits of the
KST-2000A are known and the frequency values are constrained accordingly. Press
ENTER when done.
(ODU: Enable) KST CONFIG: KST TX Æ Atten (Attenuation)
ODU Tx Attenuation:
15 dB (◄ ►,▲ ▼,ENT)
To edit the transmit attenuation: First, use the
◄ ► arrow keys to select a digit to edit, and
then use the
▲ ▼ arrow keys to change the value of that digit. Press ENTER when done.
(ODU: Enable) KST CONFIG: KST TX Æ Output
KST Tx Output:
Off On Warm (◄ ►,ENT)
Use the ◄ ► arrow keys to select OFF, ON, or WARM, and then press ENTER. Note
the following:
• WARM is OFF, if COLD.
• WARM is ON, if warm and NO FAULTS.
• If FAULTS are present, stays WARM and OFF indefinitely.
(ODU: Enable) KST CONFIG: KST TX Æ HPA
HPA: State Fault-Logic
(◄ ►,ENT)
Use the ◄ ► arrow keys to select State or Fault-Logic, and then press ENTER.
(ODU: Enable) KST CONFIG: KST TX Æ HPA Æ State
KST HPA State:
On Off (◄ ►,ENT)
Use the ◄ ► arrow keys to select On or Off, and then press ENTER.
