Comtech EF Data CDM-570 - Page 479

CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix K MN/CDM570L.IOM
K–17
If the HPA power is Off, it cannot report errors, answer messages,
provide serial numbers, etc.
(ODU: Enable) KST CONFIG: KST TX Æ HPA Æ Fault-Logic
HPA Fault Logic: Summary
No-Summary (◄ ►,ENT)
To control whether or not HPA fault will activate the SUMMARY FAULT RELAY:
Use the ◄ ► arrow keys to select Summary or No-Summary, and then press
ENTER.
(ODU: Enable) KST CONFIG: Receiver
KST RX: Frequency Atten
LNA (◄ ►,ENT)
KST RX: Frequency Atten
LNB (◄ ►,ENT)
Use the ◄ ► arrow keys to select Frequency, Atten, or LNA/LNB, and then press ENTER.
(ODU: Enable) KST CONFIG: KST RX Æ Frequency
ODU Rx Frequency:
10950.0 MHz (◄ ►,▲ ▼,ENT)
To edit the receive frequency: First, use the
◄ ► arrow keys to select a digit to edit, and
then use the
▲ ▼ arrow keys to change the value of that digit. Press ENTER when done.
(ODU: Enable) KST CONFIG: KST RX Æ Atten (Attenuation)
ODU Rx Attenuation:
15 dB (◄ ►,▲ ▼,ENT)
To edit the receive attenuation: First, use the
◄ ► arrow keys to select a digit to edit, and
then use the
▲ ▼ arrow keys to change the value of that digit. Press ENTER when done.
(ODU: Enable) KST CONFIG: KST RX Æ LNA
LNA: State Fault-Logic
Calibrate (◄ ►,ENT)
Use the ◄ ► arrow keys to select State, Fault-Logic, or Calibrate, and then press
ENTER.
(ODU: Enable) KST CONFIG: KST RX Æ LNA Æ State
ODU LNA State:
On Off (◄ ►,ENT)
(Displayed when ODU is KST-2000A unit)
(Displayed when ODU is KST-2000B unit)
(Displayed when ODU is KST-2000A unit)
