CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix K MN/CDM570L.IOM
K–18
To control whether or not the ODU provides LNA POWER via the Receive RF Cable:
Use the ◄ ► arrow keys to select ON or OFF, and then press ENTER.
(ODU: Enable) KST CONFIG: KST RX Æ LNA Æ Fault-Logic
LNA Fault Logic: Summary
No-Summary (◄ ►,ENT)
To control whether or not an LNA fault will activate the SUMMARY FAULT
RELAY: Use the ◄ ► arrow keys to select Summary or No-Summary, and then
press ENTER.
(ODU: Enable) KST CONFIG: KST RX Æ LNA Æ Calibrate
Calibrate LNA Current?
Cal Exit (◄ ►,ENT)
Calibration allows the system to determine nominal LNA power consumption. This
need only be performed at initial installation.
Use the ◄ ► arrow keys to select Cal or Exit, and then press ENTER.
(ODU: Enable) KST CONFIG: KST RX Æ LNB
LNB: State Fault-Logic
Calibrate Band (◄ ►,ENT)
Use the ◄ ► arrow keys to select State, Fault-Logic, Calibrate, or Band, and then
press ENTER.
(ODU: Enable) KST CONFIG: KST RX Æ LNB Æ State
(ODU: Enable) KST CONFIG: KST RX Æ LNB Æ Fault-Logic
(ODU: Enable) KST CONFIG: KST RX Æ LNB ÆCalibrate
The State, Fault-Logic, and Calibrate commands operate identically to those used
for the LNA (KST-2000A) unit.
Additionally:
(ODU: Enable) KST CONFIG: KST RX Æ LNB Æ Band
LNB Rx Band:
A B C (◄ ►,ENT)
Use the ◄ ► arrow keys to select A, B, or C, and then press ENTER.
(ODU: Enable) KST CONFIG: Misc (Miscellaneous)
KST MISC: AGC Ref-Adjust
(◄ ►,ENT)
Use the ◄ ► arrow keys to select AGC or Ref-Adjust, and then press ENTER.
(Displayed when ODU is KST-2000B unit)
(Displayed when ODU is KST-2000B unit)
