Step 4 Set Rail Track Upright
With the help of a second person, turn rail track upright and set it on a stable, level surface, where the
end of the Rail Track is easily accessible.
Figure 7: Rail Track Assembled
Number Description
1 Rail Track
2 Drive Rack
3 Stabilizer Feet
2
1
3
