Step 3 Attach Stabilizer Feet
Attach the Stabilizer Feet to the bottom of the Rail Track assembly using the supplied M8 screws.
Leave the screws loose until the three feet are attached and arranged in the desired location, then
tighten.
Figure 6: Installing Stabilizer Feet
Number Description
1 Rail Track
2 Stabilizer Feet
3 M8 Screws
2
1
3
