Connect other end to 4-pin socket at end of Cross Beam.
Figure 21: Connecting Lift Motor & Solenoid Cable to Cross Beam
Number Description
1 4-Pin Lift Motor & Solenoid Cable Socket
2 Cross Beam (left-end)
2
1
