2 Product Overview
34
Product Overview
2
Telephone Line Connectors
Note • The fax function may not be available depending on the model. An optional package is
necessary. For more information, contact our Customer Support Center.
• OP.TEL, LINE 2, and LINE 4 are optional.
No.
Name stamped on
the machine cover
Name on the touch
screen
Function
1 OP.TEL – Use this interface to connect an external telephone
receiver fitted with an extra G3 kit (optional). Do not
connect to the TEL connector; external telephones
cannot be connected to the TEL connector.
2 TEL – Use this interface to connect an external telephone.
Do not use this interface for external telephones
when they are fitted with an extra G3 kit (optional).
3 LINE 1 Line 1 Connect to a public telephone network.
4 LINE 2 Line 2 Connect to a public telephone network.
5 LINE 4 Line 4 Connect to a public telephone network.
5
4
1
2
3
