Configuration with expander board
▶
For the cabling with expander board, see "Connecting cables - Example
16x 2.5-inch HDDs and HDD extension box" on page 309.
For the cable plan, see "Appendix B" on page 589.
Concluding steps
▶
Install the fan bridge, see "Handling the fan bridge" on page 92
.
▶
"Installing the system air duct" on page 68.
▶
Insert all HDD/SSD modules, see "Installing a 2.5-inch HDD/SSD module"
on page 219.
Ensure that you reinstall the HDD/SSD module in the bay it was
located before the HDD backplane replacement.
▶
Insert all dummy modules, see "Installing a 2.5-inch dummy module" on
page 222.
▶
"Reassembling" on page
68
.
▶
"Connecting the power cord" on page 82.
▶
"Switching on the server" on page 83.
7.5.10 Replacing a 2.5-inch HDD SAS backplane
(configuration with up to 32 HDD/SSD modules)
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page
47
.
▶
"Shutting down the server" on page 49.
Hard disk drive (HDD) / solid state disk (SSD)
246 Upgrade and Maintenance Manual TX2550 M5
