HP Latex 3000 Series User Manual

7. Lift the base nut one extra turn by rotating counterclockwise. There are two red dots in the central shaft
for your reference.
8. Tigh
ten the base nut.
9. Tigh
ten the two screws to x the nal position of the dual-roll center support.
NOTE: Hold the support shaft rmly in position when tightening the screws.
308 Chapter 9 Troubleshoot substrate issues ENWW
