Unload the substrate (see Unload a roll on page 77) and r
emove the output spindle.
To facilitate module uninstallation, we recommend raising the carriage beam to the installation position, by
pressing the Raise carriage beam to install position button.
Uninstall the protector
1. Go to the Internal Print Server and press Uninstall ink collector.
2. Unhook the four clips from the bottom.
3. Ex
tract the protector tab from the slot.
44 Chapter 3 Handle the substrate ENWW
