4. Open the curing module latches and curing module and leave the protector to slide down softly.
WARNING! Do not touch the internal enclosures of the printer's curing module: they can be hot enough
to cause burns.
5. Remove the protector by the bottom part.
6. Remove the barriers, one on each side.
7. Check that nothing is dirty or broken. If dirty, clean with a lint-free cloth moistened with isopropyl
alcohol.
NOTE: If you are in an area (such as California) that regulates VOC cleaning and maintenance uids,
instead of isopropyl alcohol use a VOC-certiîžed cleaner such as a properly diluted Simple Green All-
Purpose Cleaner.
8. Roll up with the red side on the bottom and the black part on the top. Start rolling up on the side of the
clips.
ENWW The ink collector kit 45
