HPE FlexNetwork MSR Series Comware 5 Layer 2 - Wan Access Configuration Guide

30
[RouterB-luser-usera] password simple passa
# Set the service type of the user account to PPP.
[RouterB-luser-usera] service-type ppp
[RouterB-luser-usera] quit
# Enable PPP encapsulation on Serial 2/0.
[RouterB] interface serial 2/0
[RouterB-Serial2/0] link-protocol ppp
# Set the authentication mode to PAP.
[RouterB-Serial2/0] ppp authentication-mode pap domain system
# Configure the PAP username and password sent from Router B to Router A when Router B is
authenticated by Router A using PAP.
[RouterB-Serial2/0] ppp pap local-user userb password simple passb
# Assign an IP address to Serial 2/0.
[RouterB-Serial2/0] ip address 200.1.1.2 16
[RouterB-Serial2/0] quit
# Configure local authentication for the PPP users in the default ISP domain system.
[RouterB] domain system
[RouterB-isp-system] authentication ppp local
3. Verify the configuration:
Use the display interface serial command to display information about Serial 2/0 of Router B.
The physical layer status and link layer status of the interface are both up, and the states of LCP
and IPCP are both Opened, indicating PPP negotiation is successful. Router A and Router B
can ping each other.
[RouterB-isp-system] display interface serial 2/0
Serial2/0 current state: UP
Line protocol current state: UP
Description: Serial2/0 Interface
The Maximum Transmit Unit is 1500, Hold timer is 10(sec)
Internet Address is 200.1.1.2/16 Primary
Link layer protocol is PPP
LCP opened, IPCP opened
Output queue : (Urgent queuing : Size/Length/Discards) 0/100/0
Output queue : (Protocol queuing : Size/Length/Discards) 0/500/0
Output queue : (FIFO queuing : Size/Length/Discards) 0/75/0
Interface is V35
206 packets input, 2496 bytes
206 packets output, 2492 bytes
[RouterB-isp-system] ping 200.1.1.1
PING 200.1.1.1: 56 data bytes, press CTRL_C to break
Reply from 200.1.1.1: bytes=56 Sequence=1 ttl=255 time=103 ms
Reply from 200.1.1.1: bytes=56 Sequence=2 ttl=255 time=1 ms
Reply from 200.1.1.1: bytes=56 Sequence=3 ttl=255 time=1 ms
Reply from 200.1.1.1: bytes=56 Sequence=4 ttl=255 time=1 ms
Reply from 200.1.1.1: bytes=56 Sequence=5 ttl=255 time=10 ms
--- 200.1.1.1 ping statistics ---
5 packet(s) transmitted
5 packet(s) received
