Model 2450

Interactive SourceMeter® Instrument Reference Manual Section 2:

General operation

2450-901-01 Rev. B/September 2013 2-105

Using the front panel:

1. Press FUNCTION and select the measurement function.

2. On the Home page, select the button next to Range for the measurement type. The Select Range

dialog box is displayed.

3. Select the range. The Home page is displayed again with the selected value.

If the instrument displays an overflow message, select a higher range.

Using SCPI commands

For a current measurement, send the command:

SENSe:CURRent:RANGe:UPPer <n>

Where <n> is the positive full-scale value of the measurement range.

To set for a voltage measurement, replace CURRent with VOLTage.

To set for a resistance measurement, replace CURRent with RESistance.

Using TSP commands

For the current range, send the commands:

smu.measure.func = smu.FUNC_DC_CURRENT

smu.measure.autorange = smu.OFF

smu.measure.range = rangeValue

Where rangeValue is the positive full-scale value of the measurement range.

For a voltage measurement, replace smu.FUNC_DC_CURRENT with smu.FUNC_DC_VOLTAGE.

For a resistance measurement, replace smu.FUNC_DC_CURRENT with smu.FUNC_RESISTANCE.
