:DISPlay:<function>:DIGits
This command determines the number of digits that are displayed for measurements on the front panel.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
5
Usage
:DISPlay:<function>:DIGits <n>
:DISPlay:<function>:DIGits?
:DISPlay:<function>:DIGits? DEFault
:DISPlay:<function>:DIGits? MINimum
:DISPlay:<function>:DIGits? MAXimum
<function>
The function to which this setting applies:
• Current: CURRent[:DC]
• Resistance: RESistance
•
Voltage: VOLTage[:DC]
<n>
3.5 digit resolution: 3
4.5 digit resolution: 4
5.5 digit resolution: 5
6.5 digit resolution: 6
Details
This command affects how the reading for a measurement is displayed on the front panel of the instrument. It
does not affect the number of digits returned in a remote command reading. It also does not affect the accuracy
or speed of measurements.
The display digits setting is saved with the function setting, so if you use another function, then return to the
function for which you set display digits, the display digits setting you set previously is retained.
If you send this but do not define the function (:DISPlay:DIGits), the digits values for all functions
are changed.
Example
:DISP:CURR:DIG 5
Set the front panel to display current
measurements with 5½ digits.
Also see
None
