Model 2450

Interactive SourceMeter® Instrument Reference Manual Section 6:

SCPI command reference

2450-901-01 Rev. B/September 2013 6-27

:DISPlay:USER<n>:TEXT[:DATA]

This command defines the text that is displayed on the front-panel User Display screen.

Type Affected by Where saved Default value

Command only Power cycle Not applicable Not applicable

Usage

:DISPlay:USER<n>:TEXT[:DATA] <textMessage>

<n>

The line of the User Display on which to display text:

• Top line: 1

• Bottom line:

String that contains the message; up to 20 characters for USER1 and

32 characters for

USER2

Details

USER1 sets the text for the top line of the User Display. USER2 sets the text for the bottom line.

These commands define text messages for the User Display swipe screen.

If you enter too many characters, the instrument displays an error message and shortens the message to fit.

Example

DISP:CLE

DISP:SCR USER

DISP:USER1:TEXT "Batch A122"

DISP:USER2:TEXT "Test running"

Clear the User Display screen and switch to

display the User Display screen.

Set the first line to read "Batch A122" and

the second line to display "Test running".

Also see

:DISPlay:SCReen (on page 6-26)
