Keithley 2450 User Manual

Section
6: SCPI command reference Model 2450 Interactive SourceMeter® Instrument
Reference Manual
6-132 2450-901-01 Rev. B/September 2013
:TRIGger:BLOCk:BRANch:LIMit:CONStant
This command defines a trigger model block that branches to a block outside the normal trigger model flow if a
measurement meets preset criteria.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings
Not applicable
Usage
:TRIGger:BLOCk:BRANch:LIMit:CONStant <blockNumber>, <limitType>, <limitA>,
<limitB>, <branchToBlock>, <measureBlock>
<blockNumber>
The sequence of the block in the trigger model
<limitType>
The type of limit (
ABOVe
,
BELow
,
INside
, or
OUTside
)
<limitA>
The limit that the measurement is tested against; if limitType is set to:
• ABOVe: This value is ignored
• BELow: The measurement must be below this value
• INside: This is the low limit that the measurement is compared against
•
OUTside
: This is the low limit that the measurement is compared against
<limitB>
The upper limit that the measurement is tested against; if limitType is set to:
• ABOVe: The measurement must be above this value
• BELow: This value is ignored
• INside: This is the high limit that the measurement is compared against
•
OUTside: This is the high limit that the measurement is compared against
<branchToBlock>
The block number of the trigger model block to execute when the measurement
meets the defined criteria
<measureBlock>
The block number of the measurement block that makes the measurement to be
compared
Details
The branch-on-constant-limits block goes to a branching block if a measurement meets the criteria set by this
command.
The type of limit can be:
• Above: The measurement is above the value set by limit B. Limit A must be set, but is ignored when this
type is selected.
• Below: The measurement is below the value set by limit A. Limit B must be set, but is ignored when this
type is selected.
• Inside: The measurement is inside the values set by limits A and B. Limit A must be the low value and
Limit B must be the high value.
• Outside: The measurement is outside the values set by limits A and B. Limit A must be the low value
and Limit B must be the high value.
The measurement block must be a measurement building block that occurs in the trigger model before the
branch-on-constant-limits block. The last measurement from the measurement building block is used.
