Keithley 2450 User Manual

Model 2450
Interactive SourceMeter® Instrument Reference Manual Section 6:
SCPI command reference
2450-901-01 Rev. B/September 2013 6-35
ROUTe subsystem
The ROUTe subsystem selects which set of input and output terminals to enable (front panel or rear
panel).
:ROUTe:TERMinals
This command determines which set of input and output terminals the instrument is using.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
FRON
Usage
:ROUTe:TERMinals <location>
:ROUTe:TERMinals?
<location>
Measure using the front-panel input and output terminals: FRONt
Measure using the rear-panel input and output terminals:
REAR
Details
This command selects which set of input and output terminals the instrument uses. You can select front panel or
rear panel terminals.
If the output is turned on when you change from one set of terminals to the other, the output is turned off.
Example
:ROUT:TERM REAR
:ROUT:TERM?
Set the instrument to use the rear-panel
terminals and query to verify.
Output:
REAR
Also see
None

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
