Interactive SourceMeter® Instrument Reference Manual Section 3:
2450-901-01 Rev. B/September 2013 3-9
Using TSP commands:
Set the measurement function, and then send the commands:
smu.math.format = smu.MATH_RECIPROCAL
smu.math.enable = smu.ON
Switching math on the SETTINGS screen
Once you set the math operations settings for a measurement function, you can turn the math
function on or off on the SETTINGS swipe screen.
From the front panel:
1. Select HOME.
2. Go the SETTINGS swipe screen.
3. Select the button next to Math to change the setting.
Displayed measurements
When you make measurements, the instrument may perform operations on the measured values that
will affect what you see on the display and the measurements that are stored in the buffer.
The operations that can affect the measurement display are:
• Relative offset
• Math operations
• Limit tests
If none of these operations are set, the value that is displayed on the front panel is the actual
measurement reading.
If any of these operations are set, the value that is displayed is the measurement reading with these
operations applied. The operations are applied in the order shown above.
For example, if you made a measurement and had a relative offset and limit tests active, the
measured value would have the relative offset applied, then have limit test results applied.
