6: SCPI command reference Model 2450 Interactive SourceMeter® Instrument
Reference Manual
6-52 2450-901-01 Rev. B/September 2013
[:SENSe[1]]:<function>:RANGe:AUTO:ULIMit
When autorange is selected, this command selects the upper limit for measurements of the selected function.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
Resistance: 2e5
Usage
[:SENSe[1]]:<function>:RANGe:AUTO:ULIMit <n>
[:SENSe[1]]:<function>:RANGe:AUTO:ULIMit?
[:SENSe[1]]:<function>:RANGe:AUTO:ULIMit? DEFault
[:SENSe[1]]:<function>:RANGe:AUTO:ULIMit? MINimum
[:SENSe[1]]:<function>:RANGe:AUTO:ULIMit? MAXimum
<function>
The measurement function to which this setting applies:
• Voltage (query only): VOLTage[:DC]
• Resistance:
RESistance
<n>
The upper limit:
• Voltage: 0.02 to 200 volts
•
Resistance: 20 to 2.0e8 ohms
Details
You can use this command when automatic range selection is enabled to put an upper bound on the range that
is used for resistance measurements.
The upper limit must be more than the lower limit.
If the lower limit is equal to the upper limit, automatic range setting is effectively disabled.
Example
:SENSe:RESistance:RANGe:AUTO:ULIMit 20
Set the upper limit to 20 ohms.
Also see
[:SENSe[1]]:<function>:RANGe:AUTO (on page 6-50)
[:SENSe[1]]:<function>:RANGe:AUTO:LLIMit (on page 6-51)
