Keithley 2450 User Manual

Model 2450
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2450-901-01 Rev. B/September 2013 8-85
Example 1
test8.save()
Saves the script referenced by the variable
test8
to nonvolatile memory.
Example 2
test8.save("/usb1/myScript.tsp")
Saves the script referenced by the variable
test8 to a file named myScript.tsp on your
flash drive.
Also see
Working with scripts (on page 7-5
)
scriptVar.source
This attribute contains the source code of a script.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (R)
No
Not applicable
Not saved
Not applicable
Usage
code = scriptVar.source
scriptVar
The name of the variable that references the script that contains the source code
code
The body of the script
Details
The body of the script is a single string with lines separated by the new line character.
Example
print(test7.source)
Assuming a script named test7 was created on the instrument, this example retrieves the source code.
Output:
reset()
display.settext(display.TEXT1, "Text on User Display 1")
display.settext(display.TEXT2, "Text on line 2")
Also see
scriptVar.save() (on page 8-84)

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
