Keithley 2450 User Manual

Section
6: SCPI command reference Model 2450 Interactive SourceMeter® Instrument
Reference Manual
6-56 2450-901-01 Rev. B/September 2013
[:SENSe[1]]:<function>:RELative:ACQuire
This command acquires an internal measurement to store as the relative offset value.
Type Affected by Where saved Default value
Command Not applicable Not applicable Not applicable
Usage
[:SENSe[1]]:CURRent[:DC]:RELative:ACQuire
[:SENSe[1]]:RESistance:RELative:ACQuire
[:SENSe[1]]:VOLTage[:DC]:RELative:ACQuire
Details
This command triggers the Model 2450 to make a new measurement for the selected function. This
measurement is then stored as the new relative offset level setting.
When you send this command, the measurement is made without applying any math, limit test, or filter settings,
even if they are set. It is a reading as if these settings are disabled.
After executing this command, you can use the [:SENSe[1]]:<function>:RELative command to see the
last relative level value that was acquired or that was set.
If an error occurs during the measurement, the relative offset level remains at the last valid setting.
Example
FUNC "RES"
RES:REL:ACQ
RES:REL?
RES:REL:STAT ON
Switch to resistance measurements. Acquire
a relative offset value for resistance
measurements. Query for the offset value.
Turn relative offset on.
Also see
[:SENSe[1]]:<function>:RELative (on page 6-55)
[:SENSe[1]]:<function>:RELative:STATe (on page 6-57)

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
