8: TSP command reference Model 2450 Interactive SourceMeter® Instrument

Reference Manual

8-204 2450-901-01 Rev. B/September 2013

trigger.model.setblock() — trigger.BLOCK_CONFIG_RECALL

This attribute recalls the system settings that are stored in a measure or source configuration list.

Type TSP-Link accessible Affected by Where saved Default value

Function

Yes

Restore configuration

Instrument reset

Power cycle

Configuration script

Not applicable

Usage

trigger.model.setblock(blockNumber, trigger.BLOCK_CONFIG_RECALL, configurationList)

trigger.model.setblock(blockNumber, trigger.BLOCK_CONFIG_RECALL,

configurationList, index)

blockNumber

The sequence of the block in the trigger model

configurationList

The configuration list to recall

index

The point in the configuration list to recall; default is 1

Details

When the trigger model reaches a configuration recall building block, the settings in the specified configuration

list are recalled.

You can restore a specific set of configuration settings in the configuration list by defining the index.

Example

trigger.model.setblock(3, trigger.BLOCK_CONFIG_RECALL, "measTrigList", 5)

Configure trigger block 3 to load index point 5 from the configuration list named measTrigList.

Also see

Configuration lists (on page 3-33)
