2: General operation Model 2450 Interactive SourceMeter® Instrument
2-44 2450-901-01 Rev. B/September 2013
Figure 28: Removing the handle
2. Using a Phillips screwdriver, loosen and remove the two screws holding the handle-mount
assembly to one side of the Model 2450. The handle-mount assembly will fall away from the
instrument chassis when the screws are removed.
Figure 29: Remove the handle-mount assembly
3. Repeat step 2 on the other side of the Model 2450.
4. Store the handle-mount assembly, screws, and handle together for future use.
Remote communication interfaces
You can choose from one of several communication interfaces to send commands to and receive
responses from the Model 2450.
The Model 2450 can be controlled from only one communication interface at a time. The first interface
on which it receives a message takes control of the instrument. If another interface sends a message,
that interface takes control of the instrument.
