Keithley 2450 User Manual

Model 2450
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2450-901-01 Rev. B/September 2013 8-195
trigger.model.setblock() —
trigger.BLOCK_BRANCH_LIMIT_CONSTANT
This command defines a trigger model block that branches to a block outside the normal trigger model flow if a
measurement meets preset criteria.
Type TSP-Link accessible Affected by Where saved Default value
Function
Yes
Restore configuration
Instrument reset
Power cycle
Configuration script
Not applicable
Usage
trigger.model.setblock(blockNumber, trigger.BLOCK_BRANCH_LIMIT_CONSTANT, limitType,
limitA, limitB, branchToBlock, measureBlock)
blockNumber
The sequence of the block in the trigger model
limitType
The type of limit (trigger.LIMIT_ABOVE, trigger.LIMIT_BELOW,
trigger.LIMIT_INSIDE
, or
trigger.LIMIT_OUTSIDE
)
limitA
The lower limit that the measurement is tested against; if limitType is set to:
• trigger.LIMIT_ABOVE: This value is ignored
• trigger.LIMIT_BELOW: The measurement must be below this value
• trigger.LIMIT_INSIDE: This is the low limit that the measurement is
compared against
• trigger.LIMIT_OUTSIDE: This is the low limit that the measurement is
compared against
limitB
The upper limit that the measurement is tested against; if
limitType
is set to:
• trigger.LIMIT_ABOVE: The measurement must be above this value
• trigger.LIMIT_BELOW: This value is ignored
• trigger.LIMIT_INSIDE: This is the high limit that the measurement is
compared against
• trigger.LIMIT_OUTSIDE: This is the high limit that the measurement is
compared against
branchToBlock
The block number of the trigger model block to execute when the measurement meets
the defined criteria
measureBlock
The blockNumber of the measurement block that makes the measurement to be
compared
