Interactive SourceMeter® Instrument Reference Manual Section 6:
2450-901-01 Rev. B/September 2013 6-165
:TRIGger:LOAD:TRIGger:EXTernal
This command loads a predefined trigger model configuration.
Type Affected by Where saved Default value
Command only Not applicable Not applicable Not applicable
Usage
:TRIGger:LOAD:TRIGger:EXTernal <digInLine>, <digOutLine>, <count>
:TRIGger:LOAD:TRIGger:EXTernal <digInLine>, <digOutLine>, <count>, <delay>
:TRIGger:LOAD:TRIGger:EXTernal <digInLine>, <digOutLine>, <count>, <delay>,
<readingBuffer>
The digital input line (1 to 6); also the event that the trigger model will wait
on in block 1
The digital output line (1 to 6)
Number of times to wait for the trigger and send out the trigger
The time in seconds before the measurement is made; default is 0
The reading buffer that will store the measurement data, default is
defbuffer1
Details
This trigger model waits for a digital I/O event to occur, makes a measurement, and issues a notify event.
Also see
None
