Keithley 2450 User Manual

Section
3: Functions and features Model 2450 Interactive SourceMeter® Instrument
Reference Manual
3-132 2450-901-01 Rev. B/September 2013
Example script
The following example demonstrates how to connect to a remote device that is not TSP
®
enabled,
and send and receive data from this device:
-- Disconnect all existing TSP-Net connections.
tspnet.reset()
-- Set tspnet timeout to 5 seconds.
tspnet.timeout = 5
-- Establish connection to another device with IP address 192.168.1.51
-- at port 1394.
id_instr = tspnet.connect("192.168.1.51", 1394, "*rst\r\n")
-- Print the device ID from connect string.
print("ID is: ", id_instr)
-- Set the termination character to CRLF. You must do this
-- for each connection after the connection has been made.
tspnet.termination(id_instr, tspnet.TERM_CRLF)
-- Send the command string to the connected device.
tspnet.write(id_instr, "*idn?" .. "\r\n")
-- Read the data available, then print it.
print("instrument write/read returns: ", tspnet.read(id_instr))
-- Disconnect all existing TSP-Net sessions.
tspnet.reset()
Remote instrument errors
If the Model 2450 is connected to a TSP-enabled instrument through TSP-Net, all errors that occur on
the remote instrument are transferred to the event log of the Model 2450. The Model 2450 indicates
events from the remote instrument by prefacing these events with “Remote Error.” For example, if the
remote instrument generates error code 4909, "Reading buffer not found within device," the Model
2450 generates the error string “Remote Error: (4909) Reading buffer not found within device.”
TSP-Net instrument commands: General device control
The following instrument commands provide general device control:
tspnet.clear() (on page 8-236
)
tspnet.connect() (on page 8-237)
tspnet.disconnect() (on page 8-238)
tspnet.execute() (on page 8-239)
tspnet.idn() (on page 8-240)
tspnet.read() (on page 8-241)
tspnet.readavailable() (on page 8-242)
tspnet.reset() (on page 8-243)
tspnet.termination() (on page 8-243)
tspnet.timeout (on page 8-244)
tspnet.write() (on page 8-248)

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
