Keithley 2450 User Manual

Model 2450
Interactive SourceMeter® Instrument Reference Manual Section 6:
SCPI command reference
2450-901-01 Rev. B/September 2013 6-161
:TRIGger:LOAD:CONFiguration:LIST
This command loads a predefined trigger model configuration that uses source and measure configuration lists.
Type Affected by Where saved Default value
Command only Not applicable Not applicable Not applicable
Usage
:TRIGger:LOAD:CONFiguration:LIST <measureConfigList>, <sourceConfigList>
:TRIGger:LOAD:CONFiguration:LIST <measureConfigList>, <sourceConfigList>, <delay>
:TRIGger:LOAD:CONFiguration:LIST <measureConfigList>, <sourceConfigList>, <delay>,
<readingBuffer>
<measureConfigList>
The configuration list that contains the measurement settings to be used
for this trigger model
<sourceConfigList>
The configuration list that contains the source settings to be used for this
trigger model
<delay>
The delay time before the measurement (seconds); default is 0
<readingBuffer>
A string that indicates the reading buffer; the default buffers (
defbuffer1
or defbuffer2) or the name of a user-defined buffer; if no buffer is
specified, this parameter defaults to
defbuffer1
Details
This trigger model template incorporates a source configuration list and measure configuration list.
You must set up the configuration lists before loading the trigger model.
You can also set a delay and reading buffer.
Example
TRIG:LOAD:CONF:LIST "MyMeasList", "src config"
Load the configuration list trigger model, using the measurement configuration list
MyMeasList
and the
source configuration list src config.
Also see
None

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
